Waveshare Infrared LED Board (B), Wide Field of View
Waveshare 红外线LED板(B) 10670
条码：6922040016497
HSCode：90329000
批量修改原始型号 		采购：Cary  编辑：Shadow  产品经理：Maura

Features
1. 3W high-power 850 infrared LED
2. Onboard photoresistor, the ambient light detector
3. Onboard adjustable resistor, for controlling the ambient light threshold of toggling the infrared LED
4. Allows adding night vision function to cameras which feature embedded infrared filter :
a) 100 degree field of view, two pieces of LED is required to get wider field of view
b) Supported devices : RPi Camera (E), RPi Camera (F), RPi Camera (H)

How to Use
1. Connect the Infrared LED Board to the camera PCB by screws
2. The screw holes are used for both attachment and power supply
3. Adjust the adjustable resistor to set a proper ambient light threshold, which toggles the infrared LED automatically
4. When ambient light is lower than threshold value, the infrared LED is on, vice versa

Note :
1. Limited by the Raspberry Pi power supply, the 3W high-power infrared LED might cause the Pi to increase heating, heat sinks are suggested.
2. Ideal imaging distance is within 3m. When the distance goes up to 6m, the night vision camera can just capture blurry outlines.
特性
1. 3W大功率850红外LED
2. 机载光敏电阻，环境光探测器
3. 板载可调式电阻，用于控制红外LED开关的环境光阈值
4. 允许增加夜视功能的相机功能，内置红外滤波器:
a) 100度视野，需要两块LED才能获得更宽的视野
b) 支持设备: RPi相机(E)、RPi相机(F)、RPi相机(H)

如何使用
1. 用螺丝将红外LED板连接到相机PCB上
2. 螺孔用于连接和供电
3. 调节可调电阻，设置适当的环境光阈值，自动切换红外LED
4. 当环境光低于阈值时，红外LED亮，反之亦然

注意:
1. 受覆盆子Pi电源的限制，3W大功率红外LED可能导致Pi增加加热，建议使用散热器。
2. 理想成像距离在3m以内。当距离达到6米时，夜视相机只能捕捉模糊的轮廓。
